Input and output¶

One important aspect of programming is the ability to read and write from standard input/output and from files in different ways. Modern C++ provides two main approaches for input and output:

Modern formatted output (C++23): std::print and std::println for console output with format strings
Stream-based I/O: Stream classes for both console and file operations

This chapter will first introduce the modern approach for console output, then cover traditional stream-based I/O, and finally explore file operations where streams are particularly powerful.

Note

The std::print and std::println functions require C++23 support. If you’re using an older compiler or standard, you can use the stream-based approach or the {fmt} library as an alternative.

Modern console output (C++23)¶

C++23 introduces std::print and std::println as modern alternatives for console output. These functions use a format string syntax similar to Python’s f-strings and are generally easier to use than stream operators.

To use these functions, include the <print> header:

#include <print>

Basic printing¶

The std::println function prints text followed by a newline:

#include <print>

int main()
{
    std::println("Hello, World!");
    std::println("Another line");
}

Output:

Hello, World!
Another line

For output without a trailing newline, use std::print:

std::print("No newline here");
std::print(" - continuing on same line");

Printing variables¶

Variables are inserted using placeholders {} in the format string:

#include <print>

int main()
{
    int a = 1;
    int b = 2;
    double c = 3.14159;

    std::println("{} {} {}", a, b, c);
    std::println("a = {}, b = {}, c = {}", a, b, c);
}

Output:

1 2 3.14159
a = 1, b = 2, c = 3.14159

Formatting with format specifiers¶

Format specifiers inside {} control how values are displayed:

#include <print>
#include <cmath>

int main()
{
    double pi = 4 * std::atan(1);
    int n = 42;

    // Width and precision
    std::println("{:10.3f}", pi);        // Width 10, 3 decimals
    std::println("{:.6f}", pi);          // 6 decimal places

    // Alignment
    std::println("{:<10} left", n);      // Left aligned
    std::println("{:>10} right", n);     // Right aligned
    std::println("{:^10} center", n);    // Center aligned

    // Number bases
    std::println("{:x}", n);             // Hexadecimal
    std::println("{:#x}", n);            // Hex with 0x prefix
    std::println("{:o}", n);             // Octal
    std::println("{:b}", n);             // Binary
}

Output:

   3.142
3.141593
42         left
         42 right
    42     center
2a
0x2a
52
101010

Formatting tables¶

Format specifiers make it easy to create aligned tables:

#include <print>
#include <cmath>

int main()
{
    double x = 0.0;
    double dx = 0.1;
    double pi = 4 * std::atan(1);

    std::println("{:<15} {:>10}", "X", "f(x)");
    std::println("{:-<25}", "");

    while (x <= pi * 0.25)
    {
        std::println("{:<15.6f} {:>10.6f}", x, std::sin(x));
        x += dx;
    }
}

Output:

X                    f(x)
-------------------------
000000         0.000000
100000         0.099833
200000         0.198669
300000         0.295520
400000         0.389418
500000         0.479426
600000         0.564642
700000         0.644218

Boolean and pointer formatting¶

#include <print>

int main()
{
    bool flag = true;
    int value = 42;

    std::println("flag = {}", flag);      // Prints: 1
    std::println("flag = {:s}", flag);    // Prints: true
    std::println("address = {}", (void*)&value);  // Pointer as hex
}

Traditional stream-based console I/O¶

While std::print and std::println are the modern approach for console output, the traditional stream-based I/O using cout, cin, and cerr remains widely used and is particularly important for:

Reading input from the console (std::cin)
Legacy codebases and compatibility
File I/O operations (covered later in this chapter)

The stream classes are defined in the iostream header:

#include <iostream>

The classes in iostream are defined in the std:: namespace, so if we want to use them directly they have to be prefixed with std::.

Stream objects¶

There are 3 built-in stream objects available for console I/O:

std::cin - standard input
std::cout - standard output
std::cerr - standard error

We have already used these objects in previous sections. Now we’ll explore the details of how these work.

Writing to a stream is accomplished using the << operator followed by the variable, scalable or string that you want to write. Writing is done continuously on a single line until a special manipulator, std::"\n" or “n” is passed to the stream. It is recommended to avoid the std::"\n" manipulator as this force a flush of the output buffers which can be costly.

In the following example 3 variables are written to 2 lines of output:

#include <iostream>

int main()
{
    int a = 1;
    int b = 2;
    double c = 3.0;

    std::cout << a << " " << b;
    std::cout << " " << c << std::"\n";
    std::cout << &c << "\n"; // Recommended
}

Which gives the following output.

1 2 3
0x559fff6f0

The variables a, b and c are all written on the same line as the "\n" marker is passed after writing the c variable. You can also notice that passing a memory address to the stream will automatically format it as a hexadecimal memory address.

Reading from a stream is done by using the >> operator followed by the variables that should be assigned from the input stream. How cin is used is shown in the example below:

#include <iostream>

int main()
{
    int a;
    int b;
    double c;

    std::cin >> a >> b >> c;

    std::cout << "a = " << a;
    std::cout << ", b = " << b;
    std::cout << ", c = " << "\n";
}

In the example above the program will wait for 2 integers and a floating point number to be entered in the console before printing out the values in the std::cout statements.

Formatting output using manipulators¶

To better control how output is written C++ provides a special manipulator operators that can be passed in the stream output to control the output of data written to the stream. To use this functionality we need to use the following include:

#include <iomanip>

To control the width the output variables, the std::setw(…) manipulator can be used. This manipulator often needs to be called mutiple times as the width is usually reset if a >> or << operators are used. It is also possible to control left and right alignment using the std::left and std::right manipulators. The character used to pad the output is set by the std::setfill(…) method and the precision of floating point values are set by the std::setprecision(…) manipulator. A complete example of using these manipulators is shown below:

#include <iostream>
#include <iomanip>
#include <cmath>

int main()
{
    double pi = 4 * std::atan(1);
    double x = 0.0;
    double dx = 0.1;

    std::cout << std::setw(15) << std::left << "X";
    std::cout << std::setw(10) << std::right << "f(x)\n";
    std::cout << std::setfill('-');
    std::cout << std::setw(25) << "" << "\n";
    std::cout << std::setfill(' ');
    std::cout << std::setprecision(6) << std::fixed;
    //cout.unsetf(ios_base::fixed);

    while (x<=pi*0.25)
    {
        std::cout << std::setw(15) << std::left << x;
        std::cout << std::setw(10) << std::right << std::sin(x);
        std::cout << "\n";
        x += dx;
    }
}

The code shown above will print a function table of the std::sin(x) function.

X                    f(x)
-------------------------
000000         0.000000
100000         0.099833
200000         0.198669
300000         0.295520
400000         0.389418
500000         0.479426
600000         0.564642
700000         0.644218

It is also possible to specifiy if a boolean value should be printed as 0 or 1 or with true and false.

bool flag = true;

std::cout << "flag = " << flag << "\n";
std::cout << std::boolalpha;
std::cout << "flag = " << flag << "\n;

This prints:

flag = 1
flag = true

It is also possible to output values in different numerical bases using the hex, dec and oct manipulators. The showbase manipulator determines if output show the base in the output. The following code outputs the n integer in different bases.

int n = 42;

std::cout << std::hex << "n = " << n << "\n";
std::cout << std::hex << std::showbase << "n = " << n << "\n";
std::cout << std::oct << "n = " << n << "\n";
std::cout << std::dec << "n = " << n << "\n";

This outputs the following:

n = 2a
n = 0x2a
n = 052
n = 42

The complete example is shown below:

#include <iostream>
#include <iomanip>

int main()
{
    bool flag = true;

    std::cout << "flag = " << flag << "\n";
    std::cout << std::boolalpha;
    std::cout << "flag = " << flag << "\n";

    int n = 42;

    std::cout << std::hex << "n = " << n << "\n";
    std::cout << std::hex << std::showbase << "n = " << n << "\n";
    std::cout << std::oct << "n = " << n << "\n";
    std::cout << std::dec << "n = " << n << "\n";
}

There are a lot more manipulators available in the iomanip header. For more information please see:

cppreference.com

File I/O with streams¶

While modern std::print is excellent for console output, stream-based I/O really shines when working with files. The stream classes provide a consistent interface for reading and writing various data formats, making them ideal for file operations.

To read and write data to files we need to instantiate stream instances for each file operation. There are 3 main file stream classes in C++:

std::ofstream – output file stream
std::ifstream – input file stream
std::fstream – generic file stream

These classes are defined in the fstream standard header. Just like the std::cout and std::cin streams the file streams also use << and >> operators for input and output.

Writing to a file (ofstream)¶

To open a file for writing we can use the std::ofstream class. The first step in writing to the file is to instantiate an output file stream.

std::ofstream myfile;

Next, we open the file using the .open()-method.

myfile.open("myfile.txt");

As this is an output file stream we don’t have to give any more arguments to the .open()-method. The file is now open for writing and we can use the <<-operator for writing to the output stream.

myfile << "Hello file!" << "\n";
myfile << "Second line" << "\n";

In the output to the file we can use the same manipulators as when we were outputting to the cout standard output stream. The last statements will write 2 rows to the file myfile.txt.

The final step when reading and writing files is to tell the operating system that we will not work with the file anymore. This is done using the .close() method of the ofstream instance.

myfile.close();

The complete example is shown below:

#include <iostream>
#include <fstream>

int main()
{
    std::ofstream myfile;
    myfile.open("myfile.txt");
    myfile << "Hello file!" << "\n";
    myfile << "Second line" << "\n";
    myfile.close();
}

Hello file!
Second line

Appending to a file¶

The default behavior when writing to a file using the std::ofstream is to overwrite any existing file. If we want to append data to an existing file we can specify this using the second argument to the .open()-method, std::ios::app.

myfile.open("myfile.txt", std::ios::app);

Everything we write to the stream will now be appended to the existing file.

outfile << "Third line" << "\n";
outfile.close();

This will add “Third line” as the third line of the myfile.txt file.

Reading from a file (ifstream)¶

Reading from a file is done with the same steps as writing to a file. First, we instantiate an std::ifstream instance.

std::ifstream myfile("myfile.txt");

When reading from a file it is always a good idea to make sure the file has been succesfully opened. This can be done using the .is_open() method of the stream instance.

if (!myfile.is_open())
{
    cout << "The file couldn't be opened.\n";
    return;
}

A more generic way of checking if a file stream is ready for operations is to use the .good()-method. This method returns true if the file stream is ready for operations.

if (!myfile.good())
    return

Reading from a file requires the file to have the data in a way that the file operators can interpret. Reading data types from a file requires them to be present in the same way as they were written to the file. Writing the variables a, b and c to disk as shown in the followng example

int a = 1;
int b = 2;
int c = 3;
myfile << a << b << c;

will produce the following output to the file:

This is probarbly not what you want and it will be impossible to read the data back again as integers. To write data to a file so that it is possible to read back we need to modify our example by adding space between the variables in the output.

myfile << a << " " << b << " "<< c;

This produces the following output to the file:

1 2 3

Now it is also possible to read the data back from the file stream using the following statements:

myfile >> a >> b >> c;

Notice that variables must be added in the same order as we wrote them to the file. We don’t have to handle the extra spaces. Spaces between numbers in a file will automatically handled by the input operators.

A larger example¶

To illustrate reading and writing values to a file we will create a program that will tabulate a function and write this to the file inputfile.dat. We start by creating an output stream for writing:

double pi = 4 * std::atan(1);
double x = 0.0;
double y;
double dx = 0.1;

std::ofstream outfile;
outfile.open("inputfile.dat", std::ios::out);

Next, we use a while-loop to tabulate sin(x) from 0 to pi/4. For each row of the file we write the x value and the corresponding function value.

while (x<=pi*0.25)
{
    outfile << x << " " << std::sin(x) << "\n";
    x += dx;
}
outfile.close(); // Close file when we are done.

Notice that we add an extra space between x and std::sin(x). When running this code the file inputfile.dat will contain the following:

0
1 0.0998334
2 0.198669
3 0.29552
4 0.389418
5 0.479426
6 0.564642
7 0.644218

To read the data back from inputfile.dat we instantiate a ifstream instance.

std::ifstream infile;
infile.open("inputfile.dat");

Using a while-statement again we will read the file back. We use the .good() method to determine if we should exit the while-statement. As the input file contains values in the expected format we easily use the >>-operator for reading x and function values from the file.

while (infile.good())
{
    infile >> x >> y;
    std::println("x = {}, y = {}", x, y);
}
infile.close();

Output from the application will then be:

x = 0, y = 0
x = 0.1, y = 0.0998334
x = 0.2, y = 0.198669
x = 0.3, y = 0.29552
x = 0.4, y = 0.389418
x = 0.5, y = 0.479426
x = 0.6, y = 0.564642
x = 0.7, y = 0.644218
x = 0.7, y = 0.644218

The complete example can be found here:

#include <iostream>
#include <fstream>
#include <cmath>
#include <print>

int main()
{
	double pi = 4 * std::atan(1);
    double x = 0.0;
    double y;
    double dx = 0.1;

    std::ofstream outfile;
    outfile.open("inputfile.dat", std::ios::out);
    while (x<=pi*0.25)
    {
        outfile << x << " " << sin(x) << "\n";
        x += dx;
    }
    outfile.close();

    std::ifstream infile;
    infile.open("inputfile.dat");
    while (infile.good())
    {
        infile >> x >> y;
        std::print("x = {}, y = {}\n", x, y);
    }
    infile.close();
}

x = 0, y = 0
x = 0.1, y = 0.0998334
x = 0.2, y = 0.198669
x = 0.3, y = 0.29552
x = 0.4, y = 0.389418
x = 0.5, y = 0.479426
x = 0.6, y = 0.564642
x = 0.7, y = 0.644218
x = 0.7, y = 0.644218

Try example

Reading text files¶

Sometimes you want to read a text file and process the file yourself. To do this you can’t use the standard stream operators. To read text from a file we use the standard library function std::getline() from the sstream header. This function takes a stream as input and a string containing the line that has been read from the file. In the following example we will read from a text file containing power consumtion data in CSV format. The first column contains the date for the sample and the second column contains the power consumtion value. First we open the file:

std::string line;
std::ifstream infile;
infile.open("..\\..\\data\\AEP_hourly.csv");

if (!infile.is_open())
{
    std::println("Error opening file.");
    return 1;
}

We then do a while-loop over the file calling std::getline(…) to read the file line by line.

while (infile.good())
{
    std::getline(infile, line);
    std::println(line);
}
infile.close();

Running the example will print out something similar to:

...
2006-05-23 12:00:00,15486.0
2006-05-23 13:00:00,15545.0
2006-05-23 14:00:00,15437.0
2006-05-23 15:00:00,15455.0
2006-05-23 16:00:00,15597.0
2006-05-23 17:00:00,15437.0
2006-05-23 18:00:00,15293.0
2006-05-23 19:00:00,15058.0
2006-05-23 20:00:00,14971.0
2006-05-23 21:00:00,15166.0
...

Splitting lines¶

To separate the date from the value we need to do some basic string manipulation. First we need to find the position of the comma in the line. We can do this with the std::find(…) method. This function will return a string iterator at the position of the comma or end end() iterator. We can then use the .substr() method of the string to extract the date and value fields. The code then becomes:

while (infile.good())
{
    std::getline(infile, line);

    auto pos = std::find(line.begin(), line.end(), ',');

    if (pos != line.end())
    {
        std::string date = line.substr(0, pos - line.begin());
        std::string value = line.substr(pos - line.begin() + 1);

        std::println("date: {} value: {}", date, value);
    }
}

Running this code produces the following output:

date:  2018-01-01 12:00:00 value: 19453.0
date:  2018-01-01 13:00:00 value: 19049.0
date:  2018-01-01 14:00:00 value: 18737.0
date:  2018-01-01 15:00:00 value: 18619.0
date:  2018-01-01 16:00:00 value: 18691.0
date:  2018-01-01 17:00:00 value: 19109.0
date:  2018-01-01 18:00:00 value: 20279.0
date:  2018-01-01 19:00:00 value: 20925.0
date:  2018-01-01 20:00:00 value: 21089.0
date:  2018-01-01 21:00:00 value: 20999.0
date:  2018-01-01 22:00:00 value: 20820.0
date:  2018-01-01 23:00:00 value: 20415.0
date:  2018-01-02 00:00:00 value: 19993.0

Converting from string to float¶

If we want to convert the value field to a floating point type we can use the std::stod(…) or std::stof(…) functions. They throw an std::invalid_argument exception if the value can’t be converted. The conversion can be handled using the following code:

double dval = 0.0;

try
{
    dval = std::stod(strValue);
}
catch (const std::exception& e)
{
    std::println("{}", e.what());
}

std::println("date: {} value: {}", date, value);

Reading binary files¶

In the previous chapters we have seen how we can read and write data to text files. In many cases you will need to read and write data in binary format. Reading and writing to binary files are similar to the previous approach except that we add the std::ios::binary flag in the open-statement. and instead of using the << and >> operators we use the stream methods .read(…) and .write(…) methods for read and write. I binary file can also consist of multiple parts with different data (records). To be able to read data at different parts of the file we use an invisble cursor that we can place at the location we want to read. This cursor can be set using the .seekg(…) method of the stream.

Writing data to a binary file¶

In this example we are going to write a number of particles with position and mass to disk as a binary file. First we create a structure to hold the particle information.

struct Particle {
    double x;
    double y;
    double mass;
};

For this example we are going to write random data to our particles, so we initialise the random number generator.

std::srand((unsigned)time(0));

Next, we open a stream for binary write using the std::ios::binary flag.

std::ofstream particlesFile("particles.dat", std::ios::out | std::ios::binary);

To write particle data to the file we need create a variable to hold the data to be written:

Particle p;

To write data to a binary file the .write() method takes a pointer to a buffer of the data to write and the size of the buffer. To get a size of a buffer we can use the sizeof() function in C++ to query and variable for its size. In the following code we write 10 particles to the binary file, particles.dat.

for (auto i = 0; i < 10; i++)
{
    p.x = 100.0 * (double)std::rand() / (double)RAND_MAX;
    p.y = 100.0 * (double)std::rand() / (double)RAND_MAX;
    p.mass = 1.0 + (double)std::rand() / (double)RAND_MAX;

    particlesFile.write((char*)&p, sizeof(p));
}
particlesFile.close();

Please note that we reuse the same variable with different data for each write, which is not always the case. The .write()-method requires a char pointer, which is why we need the cast p before passing it in the call. Also p is a local variable (on the stack), which is the reason we pass it as reference using the & operator.

When writing to a binary file the invisible file pointer is moved the size of the data writting every time you call the .write()-method.

Reading data from a binary file¶

Reading data is very similar to writing data, except now we read from the file using the .read()-method and write data to a buffer of the right size. Be default the file pointer will be placed at the beginning of the file. In the following code a file object is opened for reading using the std::ios::binary flag.

std::ifstream inputParticlesFile("particles.dat", std::ios::in | std::ios::binary);

if (inputParticlesFile.is_open())
{
    while (inputParticlesFile.good())
    {
        inputParticlesFile.read((char*)&p, sizeof(p));

        std::println("x = {}, y = {}, m = {}", p.x, p.y, p.mass);
    }
}
else
    std::println("Could not open file.");

if we want to write more entries to the file at the end we can add the std::ios::ate flag when opening the file. The file pointer is then moved to the end of the file and the next entry written will be added after the last buffer written to the file.

It is also possible to move the file pointer to the end of the file using the .seekg()-method of the file stream object. The following statement moves the file pointer to the beginning of the file. The first argument is the offset to move from the position and direction given by the second argument.

inputParticlesFile.seekg(0, ios::beg);

The second argument can be on of three alternatives

std::ios::beg - search from the beginning of the file.
std::ios::cur - search from the current position forward (+) and backwards (-).
std::iso::end - search backwards from the end of the file.

If only a single argument is given to the .seekg()-method, this argument is the absolute position in the file.

Reading elevations from a binary file¶

To illustrate real-world usage of how to read data from binary file, we will open the the file ../data/colorado_elev.vit, which contains elevation values in a 400 x 400 image file. The first 268 bytes contains a header, which we will need to skip. The rest of the data contains the height values stored as unsigned bytes.

First we open the file for writing, also checking that the file was opened.

std::ifstream infile;
infile.open("../data/colorado_elev.vit", std::ios::in | std::ios::binary);

if (!infile.is_open())
{
    std::println("Error opening file.");
    return 1;
}

To be able to read the data from the file we need a buffer to store the unsigned bytes into. In this case we use a std::array with 400 x 400 in size. An unsigned byte is defined as uint8_t in C++, which we will use when we declare the array.

std::array<uint8_t, 400 * 400> buffer;

Now we need to move the file pointer to the correct position for reading the elevation values in the file. We seek 268 bytes starting from the beginning of the file.

infile.seekg(268, ios::beg);

Now we are in a position to be able to read the data. To read we use the .read() method, which takes a pointer to a buffer and the size of the buffer. The data in the std::array can be accessed by the .data()-method, but needs to be cast to the correct pointer type. We do this with the reinterpret_cast() function in C++. The size of the buffer is returned by the .size()-method.

infile.read(reinterpret_cast<char*>(buffer.data()), buffer.size());

infile.close();

This is everything required to read all the data from the binary file into our std::array. To use the data we write it back to a text file storing the data separated by commas (CSV).

To do this we open a output file stream.

std::fstream outfile;
outfile.open("../data/colorado_elev.csv", std::ios::out);

if (!outfile.is_open())
{
    cout << "Error opening file" << "\n";
    return 1;
}

Next we loop over the data in the file and write it to a text file with 400 values per row. To be able to write our uint8_t values we need to cast them to int. We do this with the static_cast() function. The final code is shown below:

for (auto i = 0; i < 400; i++)
{
    for (auto j = 0; j < 400; j++)
        outfile << static_cast<int>(buffer[i * 400 + j]) << ",";
    outfile << "\n";
}

outfile.close();

This file can be read and plotted in NumPy/Matplotlib with:

# Load data
data = np.genfromtxt('colorado_elev.csv', delimiter=',')

# Plot
plt.figure()
plt.contourf(data)
plt.title('Colorado')
plt.savefig('colorado.png')

The resulting image is shown below:

Data from binary file.
