Object-oriented programming

_images/oop.png

In procedural programming, data and subroutines are treated separately. Subroutines operate on provided data structures and variables. In object-oriented programming data and subroutines are combined into objects. Objects in numerical computing can be different matrix types, particles, vectors or solvers. The major benefits are that the actual data structures used in the implementation of an object can be hidden from the user of the object, enabling the developer of an object to improve the implementation without affecting users of the objects (encapsulation). Another important feature of object-oriented programming is the ability to inherit and extend the functionality of objects (inheritance). This enables users of objects and developers to extend and modify the functionality of existing objects, relying on the functionality of the parent object.

The functionality and data structures of objects are defined in classes in most programming object-oriented languages. Classes can be seen as templates or blueprints for objects. When an object is to be created the class is used as the template to construct the new object. Created objects are also called instances of a class.

  • Normal programs can be seen as several tasks/functions to perform.

  • An object-oriented program can be seen as several interacting objects

  • Objects can receive messages, process data, and send messages to other objects

  • Objects hide data from view. Access through methods

  • Object-oriented can be traced back to Simula 67

Key features

  • Dynamic dispatch (late binding)

    • The actual method called is determined at runtime

    • Enabled Polymorphism

  • Polymorphism

    • Several objects share characteristics

    • Shape – Circle, Rectangle, Oval

  • Encapsulation

    • Combine data and function in a single entity

    • Restricting access to actual data

  • Inheritance

    • Reuse code of an existing object/classes

    • Inherit attributes from existing classes

Classes in C++

C++ introduces the concept of a class. A class can be seen as a combination of data and functions/methods into a single entity, the class. As a language concept, it is very close to the basic struct data type in C++ in which data fields can be combined into a single user-defined data type. The class concept extends the struct data type with access methods and access attributes. The idea is that class attributes should only be accessed using methods, to hide the underlying implementation.

An example of a class could be a vector with x and y components. We can add methods for translating the vector, getting and setting the vector components and printing the component values. The first step is to define the class and the attribute variables for the coordinates, m_x and m_y, as shown in the following code:

class Vector {
    float m_x{};
    float m_y{};
};

The class declaration can be seen as a template of an object. To create a Point object we declare it just like any other variable in C++ by specifying the class Point as the type and giving a name of the object as shown in the code below:

Vector v;

However if we access the member variables, m_x and m_y

std::cout << v.m_x << ", " << v.m_y << "\n";

will produce the following error

cannot access private member Vector::m_x
  member declared at example.cpp:4:11
    std::cout << v.m_x << "\n";

Try example

which is expected behavior. By default, all attributes of a class are private, which means that we cannot access the Vector member functions. To access these member attributes we need to add access methods. To do this we need to declare public access methods in our class. In addition to doing this, we also need to specify attributes to tell the compiler which parts of the class are private and public. This is done using the private: and public: class attributes. The modified class then becomes:

#include <iostream>

class Vector {
private:
    float m_x{};
    float m_y{};
public:
    void setX(float x)
    {
        m_x = x;
    };

    void setY(float y)
    {
        m_y = y;
    };

    void set(float x, float y)
    {
        m_x = x;
        m_y = y;
    }

    float x() const
    {
        return m_x;
    };

    float y() const
    {
        return m_y;
    };

    void print() const
    {
        std::cout << "(" << m_x << ", " << m_y << ")\n";
    }

};

int main()
{
    Vector v;
    v.set(1.0, -2.0);

    std::cout << p.x() << ", " << p.y() << "\n";

    p.print();
}

In this code, we have added 6 methods 3 for assigning the m_x and m_y attributes and 2 methods for returning the values of the attributes. By using access methods like in this way, the user of the object v doesn’t need to know how the actual storage of the components is implemented. They could be stored in a remote database, but the way of assigning and retrieving the values stays the same.

Try example

Class initialisation

When declaring class variables it is important that the default state of the variables are initialised. This can be done in several ways. The easiest way is to assign default values in the declaration of class variable. In the Vector class this was done using the {}-brackets:

float m_x{};
float m_y{};

Using empty brackets will initialise the variable to its default value most of the time 0 or 0.0. It is also possible to initial values by using a class constructor. A class constructor is a special function that is called when a new object is created. This method can be used to initialise variables and do more complex initialisation operations that can’t be handled by default initialisation procedures. In the following code we have added a constructor that initialises the m_x and m_y class variables. Note that initialisation of class variables is done before the body of the function. It is possible to initialise the variables in the function body, but that is not as efficient.

#include <iostream>

class Vector {
private:
    float m_x{};
    float m_y{};
public:
    Vector()
        :m_x{-1.0}, m_y{-2.0}
    {
        std::cout << "Vector() constructor called.\n";
    }
    ...

If we create a Vector instance with the following code:

Vector v;

v.print();

will produce the following output:

Vector() constructor called.
(-1, -2)

We can clearly see that the constructor is called when the Vector object is created. We can also see that the member variables have changed their default values to -1 and -2.

Uniform initialization syntax

Modern C++ (C++11 and later) introduced uniform initialization using braces {}. This is the recommended way to create objects as it prevents narrowing conversions and is more consistent across different contexts.

Vector v1{1.0f, 2.0f};  // Recommended: uniform initialization
Vector v2(1.0f, 2.0f);  // Also works: traditional initialization
Vector v3;              // Uses default constructor

The brace initialization syntax is preferred because:

  • It prevents accidental narrowing (e.g., float to int)

  • Works consistently for all types (arrays, classes, etc.)

  • Prevents “most vexing parse” issues

Note

For Python programmers: Creating a C++ object with Vector v{1.0, 2.0}; is similar to Python’s v = Vector(1.0, 2.0), but in C++ this object is automatically managed (created and destroyed) without needing manual memory management or garbage collection.

The Rule of Zero

If no constructor is declared, C++ will automatically generate default constructors and other special member functions for your class. For simple classes like Vector that don’t manage resources (files, raw pointers, network connections), the compiler-generated versions are correct and efficient. This is known as the Rule of Zero.

The compiler automatically generates:

Vector v0;            // Default constructor (if = default or none declared)
Vector v1{1.0, 2.0};  // Custom constructor (if you provide one)
Vector v2 = v1;       // Copy constructor (compiler-generated)
Vector v3 = std::move(v1);  // Move constructor (compiler-generated)
v0 = v2;              // Copy assignment operator (compiler-generated)
v0 = std::move(v3);   // Move assignment operator (compiler-generated)

Note

Rule of Zero: If your class doesn’t manage resources, don’t write custom copy constructors, assignment operators, or destructors. Let the compiler generate them. They will be correct and efficient.

Note

For Fortran programmers: This is similar to how Fortran handles derived types with default component-wise copying, but C++ gives you more control when needed.

When the Rule of Zero applies

For the Vector class, all members (m_x, m_y) are simple types that the compiler knows how to copy. The compiler-generated copy constructor and assignment operator will correctly copy each member:

class Vector {
private:
    float m_x{0.0f};
    float m_y{0.0f};
public:
    Vector() = default;  // Explicitly request compiler-generated version
    Vector(float x, float y) : m_x{x}, m_y{y} {}

    // No need to write:
    // - Copy constructor
    // - Copy assignment operator
    // - Move constructor
    // - Move assignment operator
    // - Destructor
    // The compiler generates correct versions automatically!
};

When you need custom special members

You only need to write custom copy constructors, assignment operators, and destructors (the Rule of Five) when your class manages resources:

  • Raw pointers allocated with new (but use smart pointers instead!)

  • File handles

  • Network connections

  • Locks or other system resources

// Example of when you WOULD need custom special members:
class FileWrapper {
private:
    FILE* m_file{nullptr};
public:
    FileWrapper(const char* filename) {
        m_file = fopen(filename, "r");
    }

    ~FileWrapper() {
        if (m_file) fclose(m_file);  // Must clean up resource
    }

    // Would also need copy constructor, copy assignment, etc.
    // OR better: delete them and use move-only semantics
    FileWrapper(const FileWrapper&) = delete;  // Prevent copying
    FileWrapper& operator=(const FileWrapper&) = delete;
};

Warning

For beginners: Start with the Rule of Zero. If you find yourself writing a destructor, copy constructor, or assignment operator, ask yourself: “Should I be using a smart pointer or standard library container instead?” The answer is usually yes.

Implementing vector operations

To perform vector operations such as addition, subtraction, and scalar multiplication, we can add member functions to our Vector class. In C++, all operators in the language can be implemented as special methods added to our class implementation. The + operator is implemented using the special operator+(…) method. An example implementation of this operator is shown in the class below:

Vector operator+(const Vector& other) const {
    return Vector(m_x + other.m_x, m_y + other.m_y);
}

We can now perform operations such as:

Vector v1{1.0, 1.0};
Vector v2{2.0, 2.0};
Vector v3 = v1 + v2; // Copy constructor + operator+(...)

We can now add other operator methods in the same way. Functions for calculating scalar and cross products can be added as additional class methods.

float Vector::dot(const Vector& other) const {
    return m_x * other.m_x + m_y * other.m_y;
}

float Vector::cross(const Vector& other) const {
    return m_x * other.m_y - m_y * other.m_x;
}

Cross products and scalar product can now be calculated as shown in the following code:

Vector v5{ 1.0, 0.0 };
Vector v6{ 0.0, 1.0 };

cout << "v5.dot(v6) = " << v5.dot(v6) << endl;
cout << "v5.cross(v6) = " << v5.cross(v6) << endl;

Which gives the following output:

v5.dot(v6) = 0
v5.cross(v6) = 1

We can also add a convenient length() method:

double Vector::length() const
{
    return std::sqrt(this->dot(*this));
}

Calculating the length of a vector can now be done by calling the .length()-method.

cout << "v5.length() = " << v5.length() << endl;

Which gives us the length of 1:

v5.length() = 1

Note

The reason we add the const keyword in functions and argument lists is to indicate behavior to the compiler. The compiler can check for variable modifications and also generate more efficient code if it knows that a function will not modify the member variables of a class.

Note

For Python programmers: The const keyword is similar to Python’s convention of not modifying parameters, but C++ enforces it at compile time. A const method like length() const is similar to a Python @property - it promises not to modify the object’s state.

Modern C++ best practices summary

Before moving on to inheritance, let’s summarize the modern C++ best practices for classes:

Initialization

  1. Always use default member initializers: float m_x{0.0f};

  2. Use uniform initialization with braces: Vector v{1.0, 2.0};

  3. Use member initializer lists in constructors, not assignment in the body

  4. Explicitly use = default for compiler-generated constructors when appropriate

Memory management

  1. Prefer stack allocation for most objects

  2. Use std::unique_ptr when you need heap allocation

  3. Use std::shared_ptr only when multiple owners are truly needed

  4. Never write new or delete in modern C++ code

Special member functions (Rule of Zero/Five)

  1. Follow the Rule of Zero: Don’t write destructors, copy/move constructors, or assignment operators unless managing resources

  2. If you must write one special member function, you probably need all five (Rule of Five)

  3. Use = default to explicitly request compiler-generated versions

  4. Use = delete to prevent copying/moving when not appropriate

const correctness

  1. Mark methods that don’t modify the object as const

  2. Pass objects by const& to avoid copying

  3. Use const to document and enforce immutability

These practices will help you write safe, efficient, and maintainable C++ code that takes advantage of modern language features.

Inheritance

One of the key concepts of object-oriented programming is inheritance. Using this concept, we can define new classes that inherit behavior and attributes from existing classes. This can be beneficial, for example, if we were designing a graphics library. In our library, we want to be able to draw shapes on the screen. Many of these shapes share attributes such as position, fill color, and line color. There could also be methods for moving and querying the area of a shape.

Defining a base class Shape

To define our classes, we start by defining a base class, in this case, it could be Shape. For our shape, we need to be able to place the shape on the 2D screen, so attributes are needed for position, fill color, line color, and a display name. The code below shows an example of how a base class for our class library could look:

class Shape {
private:
    double m_x{};
    double m_y{};
    double m_fillColor[4]{ 1.0, 0.0, 0.0, 1.0 };
    double m_lineColor[4]{ 0.0, 0.0, 0.0, 1.0 };
    std::string m_name{};
public:
    Shape();
    Shape(double x, double y);
    virtual ~Shape() = default;  // Virtual destructor!

    void setPosition(double x, double y);
    double x() const;
    double y() const;

    void setFillColor(double r, double g, double b, double a);
    void setLineColor(double r, double g, double b, double a);

    void getFillColor(double& r, double& g, double& b, double& a) const;
    void getLineColor(double& r, double& g, double& b, double& a) const;

    void setName(const std::string& name);
    std::string name() const;

    virtual void print() const;
    virtual double area() const;
    virtual void draw() const;
};

We also need some common methods for our new Shape class such as .draw(), .print() and .area(). These methods should be implemented by other inherited classes and only skeleton implementations are provided by Shape. Methods that are supposed to be overridden by inherited classes should be marked with virtual. This also makes it possible for the correct methods to be called when working with a collection of different types of shapes.

As the Shape class should not intended be instantiated directly we can make sure that this is not possible by marking them as pure virtual functions. This is done by assigning them 0 in the class definitions as shown in the updated example below:

class Shape {
private:
    // ...
public:
    // ...

    // Pure virtual functions
    virtual void print() const = 0;
    virtual double area() const = 0;
    virtual void draw() const = 0;
};

Warning

Critical: When a class has virtual functions (polymorphism), it must have a virtual destructor! Without it, deleting a derived class object through a base class pointer will not call the derived class destructor, causing resource leaks.

Implementing a Circle shape.

To implement a Circle shape we create a new class definition inheriting from the Shape class.

class Circle : public Shape {
private:
    double m_radius{1.0};
public:
    Circle(double x = 1.0, double y = 1.0, double radius = 1.0);

    virtual void print() const override;
    virtual double area() const override;
    virtual void draw() const override;

    double radius() const;
    void setRadius(double radius);
};

Inheritance in a class is defined by adding : public Shape after the class name in the class definition. This tells the compiler that Circle inherits all of the public interface of the Shape class. This means that the Circle class can’t access any of the private methods or attributes from the Shape, which is what we want.

As we have an additional attribute, radius, we need to create suitable constructors. We also need to pass our constructor arguments to the Shape constructor and initialize the circle m_radius attribute. This is done just before the constructor code block.

Circle::Circle(double x, double y, double radius)
    : Shape(x, y)
    , m_radius{radius}
{
    this->setName("Circle");
}

To be able to draw a circle we need to override some of the methods of the Shape class such as print(), area() and draw().

The implementation of these classes are shown below:

void Circle::print() const
{
    Shape::print();
    cout << "radius = " << m_radius << endl;
}

double Circle::area() const
{
    double pi = 4 * std::atan(1);
    return pow(m_radius, 2) * pi;
}

void Circle::draw() const
{
    Shape::draw();
    // Draw a circle
    cout << "Drawing a circle at: (" << x() << ", " << y() << ")" << endl;
    cout << "Circle radius: " << m_radius << endl;
}

Notice that as we are overriding the print()-method of the Shape class. If we need any functionality of the base class we need to explicitely call this method from our overridden method, as shown in the print() and draw() method. For the area() method this is not required as we don’t need any functionality from the Shape area() method.

Instantiating classes and memory management

Understanding how objects are created and managed in memory is crucial for writing efficient and safe C++ code.

Stack allocation (the default choice)

To create an instance of a class, use the same syntax as for creating a variable. The following code creates a Circle object and calls the print() method.

Circle c{1.0, 1.0, 2.0};
c.print();

The output of the code will be:

Shape: Circle
Position: (1, 1)
radius = 2

Objects created this way are allocated on the stack. The stack is:

  • Fast: Allocation is just moving a stack pointer

  • Automatic: Memory is freed automatically when the object goes out of scope

  • Safe: No memory leaks possible

  • Limited in size: Typically a few MB (enough for most objects)

Note

For Python/Fortran programmers: Stack allocation is like local variables in Python or automatic variables in Fortran, but with more predictable and immediate cleanup. When the variable goes out of scope (end of block }), the destructor is called immediately - no garbage collector needed!

When to use stack allocation:

  • Default choice for most objects

  • When object size is known and reasonable (< few KB)

  • When object lifetime matches the current scope

  • For local variables, function parameters, return values

Smart pointers (when you need heap allocation)

Sometimes you need objects that outlive the current scope or are too large for the stack. Modern C++ uses smart pointers to automatically manage heap-allocated memory. Smart pointers are objects that automatically deallocate memory when it is no longer needed.

Warning

Never use raw ``new`` and ``delete`` in modern C++! Always use smart pointers instead. If you write new or delete in your code, you’re probably doing something wrong.

The following code shows how to create a Circle object using a smart pointer:

std::unique_ptr<Circle> c = std::make_unique<Circle>(1.0, 1.0, 2.0);
c->print();

When the c object goes out of scope the smart pointer will automatically delete the object.

The std::unique_ptr is a smart pointer that can only have one owner. This means that the object can’t be copied or moved to another smart pointer. If we need to transfer ownership of the object we can use the std::move function. The following code shows how to transfer ownership of the c object to a new smart pointer.

std::unique_ptr<Circle> c2 = std::move(c);

After this code, c1 will be empty (nullptr) and c2 will own the Circle object.

When to use std::unique_ptr:

  • Object needs to outlive current scope

  • Clear single owner (most common case)

  • Storing polymorphic objects in containers

  • Factory functions returning heap objects

std::shared_ptr - shared ownership

If an object needs to be shared between multiple owners, use std::shared_ptr. The std::shared_ptr keeps track of how many owners the object has and deallocates the object when the last owner is destroyed.

std::shared_ptr<Circle> c = std::make_shared<Circle>(1.0, 1.0, 2.0);
c->print();

Using std::shared_ptr, multiple pointers can share ownership:

std::shared_ptr<Circle> c1 = std::make_shared<Circle>(1.0, 1.0, 2.0);
std::shared_ptr<Circle> c2 = c1;  // OK: Both own the object

After this code, c1 and c2 both own the Circle object. When the last owner is destroyed, the object will be deallocated.

When to use std::shared_ptr:

  • Object genuinely needs multiple owners

  • Graph structures or complex relationships

  • Caching scenarios

  • When you’re unsure about ownership (but try to avoid this!)

Note

Performance consideration: std::shared_ptr has overhead (reference counting, atomic operations). Use std::unique_ptr when possible - it has zero overhead compared to raw pointers.

Practical decision guide

For scientists and engineers new to C++, here’s a simple decision tree:

1. Can the object live on the stack?

  • ✓ Yes → Use stack allocation: Circle c{1, 2, 3};

  • ✗ No → Continue to step 2

2. Does one clear owner manage the object’s lifetime?

  • ✓ Yes → Use std::unique_ptr

  • ✗ No → Continue to step 3

3. Do multiple objects need to share ownership?

  • ✓ Yes → Use std::shared_ptr

  • ✗ No → Reconsider your design or use references

Quick reference:

// Stack allocation - DEFAULT CHOICE
Circle c{1.0, 2.0, 3.0};           // Automatic cleanup, fast

// Heap with unique ownership
auto c1 = std::make_unique<Circle>(1.0, 2.0, 3.0);  // Clear ownership

// Heap with shared ownership
auto c2 = std::make_shared<Circle>(1.0, 2.0, 3.0);  // Multiple owners

// NEVER do this in modern C++:
// Circle* c = new Circle{1.0, 2.0, 3.0};  // ❌ Don't use raw new!
// delete c;  // ❌ Don't use delete!

Note

For Python programmers: Think of std::unique_ptr as clear ownership documentation (“this object owns that resource”) and std::shared_ptr as similar to Python’s reference counting, but explicit. Stack allocation is like Python locals but with immediate, predictable cleanup.

Lifetime visualization

To illustrate object lifetimes, we can create a simple class that prints out when it is created and destroyed.

class Test {
public:
    Test() { std::printf("Test() constructor called.\n"); }
    ~Test() { std::printf("~Test() destructor called.\n"); }
};

To test object lifetimes we can use curly brackets to limit the scope of the object.

{
    Test t;
}

The output of the code will be:

Test() constructor called.
~Test() destructor called.

Which is the expected output. The object is created when the scope is entered and destroyed when the scope is exited.

Let’s try the same thing using a smart pointer.

{
    std::unique_ptr<Test> t = std::make_unique<Test>();
}

The output of the code will be:

Test() constructor called.
~Test() destructor called.

Which is the expected output. The object is created when the scope is entered and destroyed when the scope is exited.

In the following example we illustrate how to use a shared pointer. In this example we create a shared pointer and transfer ownership to a new shared pointer inside another scope.

{
    std::printf("Outer scope\n");
    std::shared_ptr<Test> t = std::make_shared<Test>();
    std::printf("t.use_count() = %d\n", t.use_count());
    {
        std::printf("Inner scope\n");
        std::shared_ptr<Test> t2 = t;
        std::printf("t.use_count() = %d\n", t.use_count());
    }
    std::printf("Outer scope\n");
    std::printf("t.use_count() = %d\n", t.use_count());
}

The output of the code will be:

Outer scope
Test() constructor called.
t.use_count() = 1
Inner scope
t.use_count() = 2
Outer scope
t.use_count() = 1
~Test() destructor called.

Try example

Polymorphism

Polymorphism is the ability to operate on objects of different classes in the same way. This is achieved by using pointers to the base class. When a pointer to a base class is used to point to an object of a derived class, the derived class object can be treated as if it was a base class object. This is useful when working with collections of objects of different classes. The following code shows how to create a collection of Shape objects and call the print() method on each object.

vector<std::shared_ptr<Shape>> shapes;

shapes.push_back(std::make_shared<Circle>(1, 2, 3));
shapes.push_back(std::make_shared<Rectangle>(4, 5, 6, 7));

for (const auto& shape : shapes)
{
    shape->print();
    shape->draw();
    std::printf("Area: %f\n", shape->area());
}

The output of the code will be:

Circle at (1.000000, 2.000000) with radius 3.000000
Drawing Circle at (1.000000, 2.000000) with radius 3.000000
Area: 28.274310
Rectangle at (4.000000, 5.000000) with width 6.000000 and height 7.000000
Drawing Rectangle at (4.000000, 5.000000) with width 6.000000 and height 7.000000
Area: 42.000000

Here we can see that the print(), draw() and area() methods of the Shape class are called for each object in the collection. The print() method of the Circle and Rectangle classes are called because they override the print() method of the Shape class. The same goes for the area() and draw() methods.

Note

Polymorphism only works for pointers and references to objects. If we use objects directly, the methods of the base class will be called.

Try example

Abstract classes

An abstract class is a class that can’t be instantiated. Abstract classes are used to define a common interface for a group of classes. The Shape class is an example of an abstract class. Our current Shape class does not prevent it from being instatiated. To make the Shape class abstract we need to add a pure virtual method to the class. A pure virtual method is a method that has no implementation. Pure virtual functions are defined by assigning then 0. The following code shows how to make the Shape class abstract.

class Shape {
public:
    ...
    virtual void print() const = 0;
    virtual double area() const = 0;
    virtual void draw() const = 0;
};

When a class has a pure virtual method it can’t be instantiated. The following code will produce a compiler error.

Shape s; // Error: Can't instantiate an abstract class
std::unique_ptr<Shape> s = std::make_unique<Shape>(); // Error: Can't instantiate an abstract class

When deriving from a pure virtual class all pure virtual methods must be implemented. The following code shows how to implement the Shape class.

class Circle : public Shape {
public:
    ...
    virtual void print() const override;
    virtual double area() const override;
    virtual void draw() const override;
};

Composition

Composition is a way to combine objects to create more complex objects. Composition is used when one object is part of another object. For example, a Car object can be composed of Wheel objects. The Wheel objects are part of the Car object. The following code shows how to create a Car class that is composed of Wheel objects.

#include <array>

class Wheel {
public:
    Wheel() { std::printf("Wheel() constructor called.\n"); }
    ~Wheel() { std::printf("~Wheel() destructor called.\n"); }
};

class Car {
private:
    std::array<Wheel, 4> m_wheels;  // Modern: use std::array instead of C-style array
public:
    Car() { std::printf("Car() constructor called.\n"); }
    ~Car() { std::printf("~Car() destructor called.\n"); }
};

The following code shows how to create a Car object.

Car c;

The output of the code will be:

Wheel() constructor called.
Wheel() constructor called.
Wheel() constructor called.
Wheel() constructor called.
Car() constructor called.

When the Car object is destroyed the Wheel objects are also destroyed. The following code shows how to destroy the Car object.

~Car() destructor called.
~Wheel() destructor called.
~Wheel() destructor called.
~Wheel() destructor called.
~Wheel() destructor called.

Try example

Header and source files for classes

When working with classes it is common to split the class definition and implementation into two files. The class definition is placed in a header file with the extension .h or .hpp. The class implementation is placed in a source file with the extension .cpp. The following code shows how to split the Shape class into a header and source file. shape.h

This file contains the class definition for the Shape class. Usually the header files don’t contain the implementation of the methods, only the method signatures.

#ifndef SHAPE_H
#define SHAPE_H

#include <string>

class Shape {
private:
    double m_x{};
    double m_y{};
    double m_fillColor[4]{ 1.0, 0.0, 0.0, 1.0 };
    double m_lineColor[4]{ 0.0, 0.0, 0.0, 1.0 };
    std::string m_name{};
public:
    Shape();
    Shape(double x, double y);
    virtual ~Shape() = default;  // Virtual destructor for polymorphic base class

    void setPosition(double x, double y);
    double x() const;
    double y() const;

    void setFillColor(double r, double g, double b, double a);
    void setLineColor(double r, double g, double b, double a);

    void getFillColor(double& r, double& g, double& b, double& a) const;
    void getLineColor(double& r, double& g, double& b, double& a) const;

    void setName(const std::string& name);
    std::string name() const;

    virtual void print() const;
    virtual double area() const;
    virtual void draw() const;
};

#endif

The #ifndef, #define and #endif directives are used to prevent the header file from being included multiple times in the same file. This is called an include guard.

shape.cpp

This file contains the implementation of the Shape class. The first part of this file is the include directive for the shape.h file. This is done to make sure that the class definition is available when the implementation is compiled.

#include "shape.h"

Shape::Shape()
{}

Shape::Shape(double x, double y)
    : m_x{x}, m_y{y}
{}

void Shape::setPosition(double x, double y)
{
    m_x = x;
    m_y = y;
}

double Shape::x() const
{
    return m_x;
}

double Shape::y() const
{
    return m_y;
}

void Shape::setFillColor(double r, double g, double b, double a)
{
    m_fillColor[0] = r;
    m_fillColor[1] = g;
    m_fillColor[2] = b;
    m_fillColor[3] = a;
}

void Shape::setLineColor(double r, double g, double b, double a)
{
    m_lineColor[0] = r;
    m_lineColor[1] = g;
    m_lineColor[2] = b;
    m_lineColor[3] = a;
}

void Shape::getFillColor(double& r, double& g, double& b, double& a) const
{
    r = m_fillColor[0];
    g = m_fillColor[1];
    b = m_fillColor[2];
    a = m_fillColor[3];
}

void Shape::getLineColor(double& r, double& g, double& b, double& a) const
{
    r = m_lineColor[0];
    g = m_lineColor[1];
    b = m_lineColor[2];
    a = m_lineColor[3];
}

void Shape::setName(const std::string& name)
{
    m_name = name;
}

std::string Shape::name() const
{
    return m_name;
}

void Shape::print() const
{
    std::printf("Shape: %s\n", m_name.c_str());
    std::printf("Position: (%f, %f)\n", m_x, m_y);
}

double Shape::area() const
{
    return 0.0;
}

void Shape::draw() const
{
    std::printf("Drawing shape at: (%f, %f)\n", m_x, m_y);
}

Using this method of splitting the class definition and implementation into two files makes it easier to manage large projects. It also makes it easier to reuse classes in other projects.

Alternatives to header guards

An alternative to using include guards is to use the #pragma once directive. The #pragma once directive tells the compiler to only include the file once. The following code shows how to use the #pragma once directive.

#pragma once

#include <string>

class Shape {
    ...
};

The #pragma once directive is supported by most modern compilers and is a more modern way of preventing multiple inclusions of the same file.

Object-oriented analysis

Object-oriented analysis is the process of defining the objects and their relationships in a system. The goal of object-oriented analysis is to identify the objects in a system and how they interact with each other. The following steps are used in object-oriented analysis:

  1. Identify the objects in the system

  2. Identify the relationships between the objects

  3. Identify the attributes of the objects

The following example shows how to perform object-oriented analysis on a simple system.

Implementing a graphics library

As an example a simple graphics library will be implemented. The library will be able to draw shapes on the screen. The following objects are identified in the system:

  • Shape - The base class for all shapes

  • Circle - A circle shape

  • Rectangle - A rectangle shape

  • Line - A line shape

  • Text - A text shape

  • Composite - A composite shape

  • Canvas - The canvas where the shapes are drawn

  • Color - A color object

  • Point - A point object

  • Font - A font object

  • Pen - A pen object

  • Brush - A brush object

The relationships between the objects are:

  • Circle, Rectangle, Line, Text - Inherit from Shape

  • Composite - Contains a list of Shape objects

  • Canvas - Contains a list of Shape objects

The attributes of the objects are:

  • Shape - Position, fill color, line color

  • Circle - Radius

  • Rectangle - Width, height

  • Line - Start point, end point

  • Text - Text, font

  • Composite - List of shapes

  • Canvas - List of shapes

  • Color - Red, green, blue, alpha

  • Point - X, Y

  • Font - Name, size

  • Pen - Color, width

  • Brush - Color

We now have the base for our graphics library. The next step is to implement the classes and their relationships.

Object-oriented design of a particle system

As an example a simple particle system will be implemented. The particle system will be able to simulate particles moving in a 2D space. The following objects are identified in the system:

  • Vector - A 2D Vector class

  • BaseParticle - The base class for all particles types

  • Particle - A particle object

  • ParticleSystem - The particle system that contains the particles

  • Emitter - An emitter that emits particles

  • Attractor - An attractor that attracts particles

  • Repeller - A repeller that repels particles

  • Boundary - A boundary that contains the particles

The relationships between the objects are:

  • BaseParticle - Inherit from Point

  • Particle - Inherit from BaseParticle

  • Particle and BaseParticle - Uses Vector for position, velocity, and acceleration

  • ParticleSystem - Contains a list of Particle objects

  • Emitter - Creates Particle objects

  • Attractor - Attracts Particle objects

  • Repeller - Repels Particle objects

  • Boundary - Constrains Particle objects

The attributes of the objects are:

  • Point - X, Y

  • BaseParticle - Position, velocity, acceleration, mass

  • Particle - Lifetime, color

  • ParticleSystem - List of particles

  • Emitter - Position, emission rate

  • Attractor - Position, strength

  • Repeller - Position, strength

  • Boundary - Position, width, height

We now have the base for our particle system. The next step is to implement the classes and their relationships.

The following code shows an example of how the classes could be implemented.

class Vector {
private:
    double m_x{0.0};  // Default member initializer
    double m_y{0.0};
public:
    Vector() = default;  // Compiler-generated default constructor
    Vector(double x, double y)
        : m_x{x}, m_y{y}
    {}

    double x() const { return m_x; }
    double y() const { return m_y; }

    void setX(double x) { m_x = x; }
    void setY(double y) { m_y = y; }

    void move(double dx, double dy) { m_x += dx; m_y += dy; }
};

class BaseParticle {
private:
    Vector m_position;
    Vector m_velocity;
    Vector m_acceleration;
    double m_mass;
public:
    BaseParticle();
    BaseParticle(const Vector& position, const Vector& velocity, const Vector& acceleration, double mass);

    void setPosition(const Vector& position);
    Vector position() const;

    void setVelocity(const Vector& velocity);
    Vector velocity() const;

    void setAcceleration(const Vector& acceleration);
    Vector acceleration() const;

    void setMass(double mass);
    double mass() const;

    void move();
    void applyForce(const Vector& force);
};

class Particle : public BaseParticle {
private:
    double m_lifetime;
    Color m_color;
public:
    Particle();
    Particle(const Vector& position, const Vector& velocity, const Vector& acceleration, double mass, double lifetime, const Color& color);

    void setLifetime(double lifetime);
    double lifetime() const;

    void setColor(const Color& color);
    Color color() const;
};

using ParticlePtr = std::shared_ptr<Particle>;

class ParticleSystem {
private:
    std::vector<ParticlePtr> m_particles;
public:
    ParticleSystem();

    void addParticle(const ParticlePtr& particle);
    void removeParticle(const ParticlePtr& particle);

    void update();
    void draw();
};

class Emitter {
private:
    Vector m_position;
    double m_emissionRate;
public:
    Emitter(const Vector& position, double emissionRate);

    void setPosition(const Vector& position);
    Vector position() const;

    void setEmissionRate(double emissionRate);
    double emissionRate() const;

    ParticlePtr emit();
};

class Attractor {
private:
    Vector m_position;
    double m_strength;
public:
    Attractor(const Vector& position, double strength);

    void setPosition(const Vector& position);
    Vector position() const;

    void setStrength(double strength);
    double strength() const;

    Vector force(const ParticlePtr& particle) const;
};

class Repeller {
private:
    Vector m_position;
    double m_strength;
public:
    Repeller(const Vector& position, double strength);

    void setPosition(const Vector& position);
    Vector position() const;

    void setStrength(double strength);
    double strength() const;

    Vector force(const ParticlePtr& particle) const;
};

class Boundary {
private:
    Vector m_position;
    double m_width;
    double m_height;
public:
    Boundary(const Vector& position, double width, double height);

    void setPosition(const Vector& position);
    Vector position() const;

    void setWidth(double width);
    double width() const;

    void setHeight(double height);
    double height() const;

    void constrain(ParticlePtr& particle);
};

Comments on object-oriented analysis

Object-oriented analysis is a powerful tool for designing complex systems. By identifying the objects in a system and how they interact with each other, we can create a clear and concise design. Object-oriented analysis is used in many fields, including software development, engineering, and business. By using object-oriented analysis, we can create systems that are easy to understand, maintain, and extend.

When using object-oriented analysis in computational science it is also important to consider the performance of the system. Object-oriented programming can introduce overhead in terms of memory and processing time. It is important to consider the trade-offs between performance and maintainability when designing a system.

Performance considerations for particle systems

In the previous example the Particle class was instantiated in a std::vector with every particle allocated on the heap using std::shared_ptr. This design can lead to performance issues when the number of particles is large. Consider these modern C++ alternatives:

1. Store objects directly in containers (best performance):

std::vector<Particle> particles;  // Particles stored contiguously in memory
particles.emplace_back(position, velocity, ...);  // Construct in-place

2. Use std::unique_ptr for polymorphism:

std::vector<std::unique_ptr<BaseParticle>> particles;  // Lower overhead than shared_ptr

3. Structure of Arrays (SoA) layout for maximum performance:

class ParticleSystem {
private:
    std::vector<Vector> m_positions;     // All positions together
    std::vector<Vector> m_velocities;    // All velocities together
    std::vector<double> m_masses;        // All masses together
    // Better cache locality, enables SIMD optimizations
};

General performance tips:

  • Store objects directly in containers when possible (avoid pointers)

  • Use std::vector with reserve() to avoid reallocations

  • Consider memory layout for cache efficiency (SoA vs AoS)

  • Use std::unique_ptr instead of std::shared_ptr when possible

  • Profile before optimizing - clarity first, optimize bottlenecks later

Note

For scientists: Start with the clearest design (objects in vectors). Profile your code to find actual bottlenecks. Modern compilers are excellent at optimizing clean, simple C++ code. Premature optimization often makes code harder to understand without meaningful performance gains.
